HARLEM - 5 Piece Kitchen Doors
The Harlem door provides the perfect balance between classic and contemporary, with its full range of on-trend finishes and its beautiful shaker frame design.
5 Piece Shaker Style Door with 60mm Stiles wrapped in Solid, Uni-Colour, Legno Grain Embossed Vinyl with a 22mm Thick MDF Core
12mm center panel
Off Stand and Made to Measure sizes also available - Price as next size up +50%. Please note clearly at Checkout the size required.
Plain frames are available on standard size doors at standard door price +50%.
Harlem Kitchen Doors:
Kitchen Door sizes between 283 - 2400mm high are supplied 5-piece as standard. The centre panel grain direction will always be vertical. Minimum Door width 246mm. Beneath this a 146mm single wrapped profile can be ordered MTM in height only.
Mid-Rails are not available. Multiple Panel Bedroom Doors are not available.
Harlem Drawers:
Drawer sizes between 100 - 215mm high are supplied as 1-piece flat panels (See drawer visual for reference). MTM height Drawers are manufactured from the next
nearest profile size (115, 140, 146, 175 and 215mm high) with the bottom cut and edged. This edge should always be placed at the bottom during installation. Drawers are supplied with horizontal grain. Minimum Drawer width 246mm. Drawers are not available between 216 – 283mm high. Pan Drawer sizes between 283 - 355mm high are supplied as 5-piece. The centre panel grain direction will always be vertical. Minimum Pan Drawer width 246mm. It’s important to specify either Door, Drawer or Pan Drawer when ordering to ensure your order is processed correctly.
Harlem Frames:
Full Open Frames between 283 - 2400mm high are supplied as single panels as standard. It’s important to always specify either Full Open Frame when ordering to
ensure your order is processed correctly. Top Open Frames are not available. Georgian Frames are not available. Standard Kitchen Frame sizes are supplied glazed. Non-Standard Frame Sizes are supplied unglazed. Non-Standard MTM Frames are supplied as individual pieces and require manual assembly. Minimum Frame width is 246mm.
Harlem Curved Doors:
Curved Doors are made to suit 300 x 300mm cabinets only. Height availability ranges from 570mm up to 2250mm. Curved Doors are supplied as single panels as standard. The centre panel grain direction will always be vertical. Mid-Rails are not available.
Concave Doors are not available.
